All specifications are approximations, and are subject to verification.
“On Our Floor now, Can be inspected under Power.

MACHINE SPEC
Make: LEADWELL
Model #: V-40
Serial #:
Country of Origin: TAIWAN
Year of Manufacturing: 2004

Equipped With:
LM Ways Design
CNC Control FANUC 0iMB
HIGH pressure Coolant
Comes with Books, Parameters Backup.

Specifications:
Table Size: 1200 x 500 mm
Travel X ,Y ,Z : 1020 X 510 X 510 mm
Rapid Traverse : 20,000 mm/min
Distance Between Spindle Nose & Table Top : 160-670 mm
Spindle taper: BT40
Spindle Speed: 8,000 rpm
Spindle Motor:  11/15kVA
ATC: 24 tool ARM  type

General:
Power Requirement:  28kVA
Weight : 4,500 kgs Approx.
