All specifications are approximations, and are subject to verification.
“On Our Floor now, Can be inspected under Power.

MACHINE SPEC
Make: KITAMURA
Model #: HX-500i
Country of Origin: Japan

Equipped With:
Box Ways Design
CNC Control FANUC 21iMB
Coolant System.
With Through Spindle Coolant
Comes with Books, Parameters Backup.

Specifications:
Table Size: 500 x 500 mm
Table Indexing : 0.001 degree
Max working size: 800x1090mm
Max Table load: 800kg
Travel X ,Y ,Z : 870x710x660 mm
Rapid Traverse : 50,000mm/min
Spindle taper: 50
Spindle Speed: 12,000 rpm ( integrated spindle )
Spindle Motor:  28.5kVA
ATC: 60 tool ARM  type high speed servo ATC

General:
Power Requirement:  55 kVA
Weight :  20,100 kgs Approx.
