Kitagawa B-210 Open Centre Power Chuck Product code: B-210



254 mm three jaw power chuck with 75mm through hole and max speed of 4200rpm.

  • Grip Range (mm):  254 max, 31 min
  • Jaw Stroke (diameter mm): 8.8
  • Max Gripping Force (kN): 111
  • Lubrication nipple on each master jaw
  • Master Jaw Serration: 1.5mm x 60°

Kitagawa's leading power chuck can be used with both hard and soft jaws.



Key Features

Chucks are manufactured from high grade alloy steel. Three jaw wedge style power chucks deliver up to 20% more speed, gripping force and bore size when compared to conventional chucks.

  • Through-hole (mm): 75
  • Gripping range (mm): 254 max, 31 min
  • Jaw Stroke (diameter mm): 8.8
  • Plunger Stroke (mm): 19
  • Max. Draw Bar Pull Force: 43kN, 4385 kgf
  • Max. Gripping Force: 111 kN, 11319 kgf
  • Max Speed: 4200rpm
  • Weight (with soft jaws) 34.5kg
  • Moment of inertia: 0.315 kg.m2
  • Matching cylinder: S1875
  • Max pressure: 2.7 MPa, 27.5 cm2
  • Matching hard top jaw: HB10A1
  • Matching soft top jaw: SB10B1



Bundle includes

1 New Kitagawa B210 chuck

1 New Kitagawa Flange / adaptor plate

1 New kitagawa  soft jaws set



All the items come with standard Kitagawa warranty from Kitagawa India PVt LTD

    ₹73,000.00 Regular Price
    ₹63,875.00Sale Price
